21 Oct '21

Cutting ruby CI pipeline times with pre-installed bundles

I (and, increasingly many of my colleagues) are using Jekyll to create open (CC-licenced), hackable, acessible course websites & teaching content for our classes. We use a self-hosted GitLab server for all the websites sources, and then build/deploy them with GitLab CI. It works well, it means I don’t have to fight with our LMS to do interesting things, and it means I can open my learning materials to everyone (not just those who are privileged enough to be able to pay the fees to study at the ANU).

The jekyll build step runs in a container, and for a long time we’ve just used the official ruby image as a starting point, then done a bundle install inside the container before running the build step to get all the deps. However, this means the deps are installed from scratch on every deploy, which isn’t the greenest (although ANU is heading in a good direction on net zero) and it also means the feedback loop from push->deployed site is much longer than it needs to be.

Yesterday (prompted by the understandable frustrations of my colleague Charles about the build times) I spent some time fixing things. I ended up creating a new docker image with the required gems pre-installed, and it cut our CI pipeline times by up to 90% (i.e. a 10x speedup).

There were a couple of tricky parts, so I include some commentary here in case anyone else (including future me when if I forget how this works) wants to do similar things.

# Choose and name our temporary image.
FROM ruby:3.0.2 as builder

WORKDIR /app

# Take an SSH key as a build argument.
ARG SSH_PRIVATE_KEY

# required to pull from the (private) theme gem repos
# create the SSH directory.
RUN mkdir -p ~/.ssh/ && \
  # populate the private key file.
  echo "$SSH_PRIVATE_KEY" > ~/.ssh/id_rsa && \
  # set the required permissions.
  chmod -R 600 ~/.ssh/ && \
  # add our GitLab server to our list of known hosts for ssh.
  ssh-keyscan -t rsa gitlab.anu.edu.au >> ~/.ssh/known_hosts

# install the deps - this is really just for "caching", the expectation is that
# the CI job will re-run `bundle install` to pick up any differences
COPY Gemfile Gemfile.lock* .
RUN bundle install

# Choose the base image for our final image
FROM ruby:3.0.2
WORKDIR /app

# Copy across the files from our `builder` container
# this really assumes the same base container
COPY --from=builder $BUNDLE_APP_CONFIG $BUNDLE_APP_CONFIG

The main tricky bit is the ssh setup, because some of the (in-house) gems are only available in git repos which require authentication. This Dockerfile pulls in the SSH key from an environment variable, then uses it to bundle install the required gems. Then, the key part is that there’s a second FROM command to create a new image (sans any trace of the SSH key) and only the installed gems are copied across.

To build the container, you need to do something like

MY_KEY=$(cat gitlab-ci-runner-key)
docker build --build-arg SSH_PRIVATE_KEY="$MY_KEY" --tag YOUR_TAG_NAME .

A couple of caveats with this approach: the container just caches the gems; the bundle install step will still (probably) need to run in the CI pipeline, but it’ll be a no-op if Gemfile.lock hasn’t changed. You’ll never be worse off (time-wise) than if you’re installing from scratch, because only the deps which have changed in the lock file will be downloaded. But over time, the container may take longer to run as the list of pre-installed vs actually required packages diverges.

I did try a similar approach that used bundle cache to pull all the deps into a vendor/cache folder and then copy that across into the new image, but I had weird permissions errors that I didn’t have the time to figure out. If you’ve got tips on whether that’s a more “bundler-y” way to do things then hit me up.

I want to give a shoutout to Jan Akerman who wrote a helpful blog post which got me started—and some of the Dockerfile is taken from that post.
