Getting a reTerminal DM running as a Nerves kiosk in 2026

8 Apr 26

dev

The Neon Perceptron is a physical neural network I’m building with my colleague Brendan Traw—a modern take on Rosenblatt’s Perceptron where every wire is a flexible LED that lights up with its activation. I wrote about the interactive digital twin a few months back.

The brain of the thing is a Seeed reTerminal DM—essentially a Raspberry Pi Compute Module 4 in an industrial enclosure with a 10.1” capacitive touchscreen, GPIO, and CAN bus. It runs Nerves (Elixir’s embedded Linux framework) with a Phoenix LiveView UI displayed in a fullscreen kiosk browser.

Getting all of this working with a current stack took more yak-shaving than I’d hoped. Here’s what I learned, so you don’t have to.

#The display problem

The reTerminal DM’s 800×1280 DSI display uses an ILI9881D panel controller with a Goodix GT9271 capacitive touchscreen. Neither of these are in the mainline Linux kernel’s driver set—the panel’s compatible string (gjx,gjx101c7) doesn’t match the upstream panel-ilitek-ili9881c driver, so if you boot a stock Nerves system the DRM pipeline never initialises and the screen stays black.

I initially tried kiosk_system_rpi4—a maintained Nerves system with Cog/WPE built in—but hit this wall immediately. The ElixirForum thread on browser kiosks in Nerves was invaluable here, as was the bringing up cool hardware with Nerves thread where others had got the reTerminal working. The solution was to fork formrausch/frio_rpi4, a Nerves system that includes the custom panel-ili9881d.c kernel module and device tree overlays for the reTerminal DM hardware. Our fork is at ANUcybernetics/reterminal_dm.

The frio_rpi4 system was on an older nerves_system_br (1.28.3) and OTP 27, so I updated it to nerves_system_br 1.33.4 and OTP 28. This also meant rewriting the firmware update config (fwup.conf) to use the RPi4’s modern tryboot A/B partition scheme¹, which gives you automatic rollback if a firmware update fails to boot.

#Booting and the kiosk stack

The DSI display requires a specific initialisation dance in Application.start/2, before the compositor launches:

defp prepare_hardware do
  # start udevd so the touchscreen gets enumerated
  System.cmd("udevd", ["--daemon"])
  System.cmd("udevadm", ["trigger"])
  System.cmd("udevadm", ["settle"])

  # reload the vc4 DRM driver---the DSI panel needs this
  System.cmd("modprobe", ["-r", "vc4"])
  Process.sleep(500)
  System.cmd("modprobe", ["vc4"])
  Process.sleep(1000)

  # suppress kernel messages on the display
  :os.cmd(~c"dmesg -n 1")

  # re-enumerate after vc4 reload
  System.cmd("udevadm", ["trigger"])
  System.cmd("udevadm", ["settle"])
end

Skip any of these steps and you’ll get either a black screen, no touchscreen, or kernel log spam over your UI. The vc4 reload is the key bit—without it the DRM device doesn’t fully initialise for the DSI panel. Credit to the frio_rpi4 README for documenting this workaround.

After prepare_hardware, a supervision tree starts:

1. seatd (seat daemon)—manages access to input and DRM devices
2. Weston (Wayland compositor)—runs in kiosk-shell mode, no panel, no cursor. Make sure you don’t pass --continue-without-input—despite the name, it doesn’t just mean “start even if no input devices are found.” It skips input device enumeration entirely, so Weston never discovers the touchscreen.
3. Cog (minimal WPE WebKit browser)—connects to Weston via --platform=wl and loads http://localhost:4000/ui

All three are managed as MuonTrap daemons under a rest_for_one supervisor, so if Weston crashes, Cog gets restarted too.

I’d previously done scripted RPi kiosk setups with Raspberry Pi OS and labwc, but Nerves gives you something qualitatively different: the entire system—OS, compositor, browser, application—is a single firmware image that you build with mix firmware and deploy over the air with mix upload nerves.local. No SD cards, no apt-get, no configuration drift.

#The touch problem

This is the frustrating part. The Goodix touchscreen works fine at the kernel level—/dev/input/event0 delivers events, Weston picks them up via libinput and associates them with the DSI-1 output. But Cog 0.18.5 / WPE WebKit 2.48.3 simply does not forward those touch events to the browser. No pointerdown, no touchstart, no click—nothing reaches the DOM.

This is a known category of issues in Cog. The Wayland platform backend’s touch handling has had multiple bugs (multitouch broken, long-press not working, fd leaks), and while there have been patches, the fundamental wl_touch forwarding doesn’t work reliably on this hardware.

I investigated several alternatives:

• Cog’s DRM platform (--platform=drm) bypasses Weston and uses libinput directly, which should fix touch. But the current system doesn’t compile Cog with DRM platform support—it SIGABRTs on launch. Adding BR2_PACKAGE_COG_PLATFORM_DRM=y to the Buildroot defconfig and rebuilding would likely work, but I haven’t done that yet.

• webengine_kiosk (Qt WebEngine for Nerves) manages input directly from /dev/input, bypassing Wayland entirely. But it’s been archived since 2021 and targets Qt5; the current Buildroot ships Qt6.

• The virtualinput fix from meta-wpe#224 only applies to wpebackend-rdk, not the standard Cog Wayland platform.

#The workaround: server-side touch with synthetic events

Rather than rebuild the system image (again), I went server-side. The pipeline is:

Goodix touchscreen
  → /dev/input/event0 (kernel evdev)
  → InputEvent library (Elixir, poll-based)
  → Touch GenServer (processes raw events, broadcasts via PubSub)
  → LiveView subscribes, calls push_event/3
  → JS hook dispatches synthetic PointerEvents on the correct DOM element

The Touch GenServer reads raw evdev events—abs_mt_position_x, abs_mt_position_y, btn_touch, syn_report—and broadcasts {:touch, :down | :move | :up, {x, y}} tuples via Phoenix PubSub. The LiveView forwards these to the browser with push_event, and a colocated JS hook dispatches real PointerEvent objects:

dispatchSyntheticPointer(type, x, y) {
  const target = document.elementFromPoint(x, y) || document.body;
  target.dispatchEvent(new PointerEvent(pointerType, {
    bubbles: true,
    cancelable: true,
    clientX: x,
    clientY: y,
    pointerId: 1,
    pointerType: "touch",
    isPrimary: true,
  }));
}

From the browser’s perspective, these look like native touch events. Any JS library or CSS :active state that listens for pointer events will work. The round-trip latency through the server is negligible on localhost—the whole thing runs on the same device.

#Other things that’ll bite you

NIF cross-compilation. If you’re using NIFs on Nerves, make sure they actually cross-compile for your target. I had NxEigen in my deps, and cc_precompiler silently skipped building the NIF for aarch64-nerves-linux-gnu because no prebuilt binary existed. The firmware built fine, but the app crash-looped on boot because libnx_eigen.so was missing. I ended up dropping it in favour of Nx.BinaryBackend on the target².

Partition scheme migration. If your device was originally flashed with one partition layout (e.g. kiosk_system_rpi4’s tryboot scheme) and you try to OTA a firmware image built for a different layout (e.g. frio_rpi4’s older MBR-swap scheme), the upload will appear to succeed but write to the wrong partitions. The fix is a full reflash via rpiboot. This only bites you once, during the initial migration, but it’s confusing when it happens.

eMMC-only boot. The reTerminal DM has no SD card slot—it boots exclusively from 32GB eMMC. For the initial flash, you need to toggle the boot switch next to the USB-C port, connect to a Linux machine, run rpiboot to expose the eMMC as a block device, and then mix firmware.burn. After that, OTA updates via mix upload work fine—the A/B partition scheme means you can’t brick the device remotely³.

#Summing up

If you’re trying to get a reTerminal DM running with a modern Nerves stack, here’s what you need:

1. A custom Nerves system with the ILI9881D panel driver and reTerminal DM device tree overlays—stock systems won’t drive the display. Start from frio_rpi4 or use our fork directly.

2. A vc4 driver reload in your application startup, before the compositor launches.

3. Server-side touch input via the input_event library, because Cog/WPE’s Wayland touch forwarding is broken. Dispatch synthetic PointerEvents from a LiveView hook and everything just works.

4. rpiboot for the initial eMMC flash, then OTA from there.

The source is at ANUcybernetics/neon-perceptron.

Next up: the Neon Perceptron’s output layer uses multiple Nerves devices driving seven-segment displays, so I need to get BEAM clustering working across a few CM4s on a local network. The nice thing about Nerves is that distributed Erlang is just… there. libcluster with gossip discovery, a gigabit switch, and suddenly GenServer.call works across devices. But that’s a post for another day.
