I’m about to design and build a modern interpretation of Rosenblatt’s Perceptron. It’s called the Neon Perceptron becausever wire will be a flexible LED that’ll light up with it’s “activation”. I’m doing the software, my colleague Brendan Traw is designing some custom PCBs and other hardware, and we’re working on the overall design together.

This post contains a digital twin of the current design, just to help us get a feel for how it’ll look and work. While the physical version is still a work in progress, you can play with this interactive 3D version right now.

Draw on the 5×5 blue input grid (on the left) and watch the activations flow through the network to the output layer. The coloured lines show you what’s happening inside: orange for positive activations, blue for negative, with brightness and thickness showing the magnitude.

Wire gamma: 2.2

How it works

The neon perceptron has three layers:

1. Input layer (left): a 5×5 grid of pixels. Click and drag to “draw” on it.
2. Hidden layer (middle): 9 neurons with tanh activation.
3. Output layer (right): 10 neurons with softmax activation, displayed as seven-segment displays showing digits 0–9.

The coloured lines show the weighted connections between neurons—orange for positive activations (the input is reinforcing this connection), blue for negative (the input is inhibiting it). Line thickness and brightness indicate the magnitude of the activation.

The weights are randomly initialised, so hit “Randomise” to generate a new set. Since the network hasn’t been trained on anything, it won’t actually recognise digits^[1]. But you can see how different input patterns produce different output distributions.

Controls

• Reset: clear the input grid
• Randomise: generate new random weights
• Fullscreen: expand to fill your screen (press Escape to exit)
• Wire gamma: adjust how bright the connection lines appear (higher values make weak activations more visible)

You can also click and drag on the background to orbit the camera, and scroll to zoom.

The maths

The forward pass is straightforward:

hidden = tanh(input @ W1)
output = softmax(hidden @ W2)

Where W1 is a 25×9 weight matrix and W2 is a 9×10 weight matrix. The weights are initialised using Xavier/Glorot initialisation.

The seven-segment displays show the softmax probability for each digit class—brighter segments indicate higher probability. Since the weights are random, you’ll see fairly uniform (and nonsensical) output distributions.

---

1. In the physical neon perceptron, we’re planning to train it by manually adjusting potentiometers—proper old-school analogue computing. ↩︎
